Description
Part Number: DHIPPTZ40/25XLR-P-D
Brand: SPRO
Camera Resolution 4 Megapixels
Codec recording H.265
IR Distance Up to 100m IR distance
Active Deterrence Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
Style PTZ
ColourNight 2.0 Yes
The SPRO DHIPPTZ40/25XLR-P-D camera IS engineered to meet the demanding needs of modern security systems. This camera integrates a dual-lens design, combining a panoramic camera for wide-area coverage with a detailed camera for high-resolution close-ups. This dual-camera configuration not only delivers expansive and vivid imagery but also supports independent operation of each camera, offering unparalleled flexibility in surveillance applications.
Ideal for large-scale installations, the SPRO DHIPPTZ40/25XLR-P-D is designed to optimise operational efficiency and reduce costs. Its integrated smart tracking capability leverages both cameras to accurately follow moving objects, enhancing security monitoring capabilities. Additionally, the camera's design significantly reduces installation expenses by eliminating the need for multiple discrete camera units.
Key Features:
- Active Deterrence 2.0
- ColourNight 2.0
- Audio over cable
- AI Pro
- SMD 4.0
- Starlight
- Panorama: 1/2.8” 4 Megapixel F1.0 STARVIS CMOS
- Detail: 1/2.8” 4 Megapixel CMOS
- 25x optical zoom
- Max. 25/30fps@4M.
- Built-in 2/1 alarm in/out
- IR distance up to 100m (Smart IR)
- IP66
- Tripwire
- Intrusion
- Face Detection
| Specifications: | |
|---|---|
| Model Number | DHIPPTZ40/25XLR-P-D |
| Image Sensor | Panorama: 1/2.8” CMOS | Detail: 1/2.8” CMOS |
| Pixels | Panorama: 4MP | Detail: 4MP |
| Max. Resolution | Panorama: 2560 (H) × 1440 (V) | Detail: 2560 (H) × 1440 (V) |
| ROM | Panorama: 4GB | Detail: 4GB |
| RAM | Panorama: 1GB | Detail: 1GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Panorama: 1/3s-1/100000s | Detail: 1s-1/30000s |
| Scanning System | Progressive |
| Min. Illumination | Panorama: 0.001 lux@F1.0 (Colour, 30 IRE); 0.0005 lux@F1.0 (B/W, 30 IRE); 0 lux (illuminator on); Detail: 0.005 lux@F1.6 (Colour, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (illuminator on) |
| Illumination Distance | Panorama: 30 m (98.43 ft) (IR); 30 m (98.43 ft) (white light); Detail: 100 m (328.08 ft) (IR) 50 m (164.04 ft) (white light) |
| Illuminator On/Off Control | Panorama: Auto; Manual; Off; Detail: Zoom Prio; Auto; Manual; Off |
| Illuminator Number | Panorama: 2 (IR); 2 (white light) | Detail: 2 (IR); 2 (dual light Fusion) |
| Lens | |
| Focal Length | Panorama: 2.8 mm | Detail: 5 mm – 125 mm |
| Max Aperture | Panorama: F1.0 | Detail: F1.6 – F3.6 |
| Field of View | Panorama: H: 101°; V: 53°; D: 120°; Detail: H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7° |
| Optical Zoom | Panorama: NA | Detail: 25× |
| Focus Control | Auto / Semi-Auto / Manual |
| Close Focus Distance | Panorama: 0.2 m (0.66 ft)| Detail: 0.1 m–0.5 m (0.33 ft–1.64 ft) |
| DORI Distance | Detect: 2500 m (8202.10 ft) Observe: 987.5 m (3239.83 ft) Recognise: 500 m (1640.42 ft) Identify: 250 m (820.21 ft) |
| PTZ | |
| Pan/Tilt/Rotation | Panorama: Tilt: 13° to 23°; Detail: Pan: 0° to 360° endless; Tilt: –15° to 90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1°/s–200°/s | Tilt: 0.1°/s–120°/s |
| Preset | 300 |
| Preset Speed | Pan: 240°/s | Tilt: 200°/s |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Pattern; Preset; Scan; Tour |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linking the detail camera to track objects |
| Auto Tracking | Yes |
| SMD | SMD 4.0 |
| Quick Pick | Yes |
| Active Deterrence | |
| Light Warning | Red-blue light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low |
| Sound Warning | Offers 11 sound alarms and supports importing custom sound alarms. |
| Video | |
| Video Compression | H.265; H.264B; H.264; H.264H; MJPEG(Sub Stream 1); smart H.265+; smart H.264+ |
| Streaming Capability | 3 Streams |
| Resolution | Panorama: 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 ×288/352 × 240) Detail: 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 4 MP/3 MP/1080p/1.3 MP/720p@(1–25/30 fps) Sub stream 1: D1/CIF/VGA@(1–25/30 fps) Sub stream 2: 1080p/1.3 MP/720p@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 96 Kbps–14848 Kbps H265: 38 Kbps–8960 Kbps |
| Bit Rate Control | Variable Bit Rate (VBR) /Constant Bit Rate (CBR) |
| Bit Rate | Default resolution of the main stream: H264: 2816 kbps–8192 kbps H265: 1024 kbps–7936 kbps |
| Day/Night | Auto (ICR) / Colour / B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto/ Manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilisation | EIS |
| Defog | Electronic |
| Digital Zoom | 16x |
| Image Rotation | 180° |
| S/N Ratio | ≥ 55 dB |
| Audio | |
| Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP |
| Interoperability | ONVIF(Profile S&G&T);CGI;SDK |
| Streaming Method | Unicast / Multicast |
| Storage | Micro SD card (512GB): FTP / SFTP; NAS |
| User / Host | 20 (total bandwidth: 64M) |
| Browser | IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; Safari 10 and later versions |
| Management Software | DMSS |
| Mobile Client | iOS; Android |
| Port | |
| Audio Input | 1 (LINE IN; bare wire) |
| Audio Output | 1 channel (LINE OUT, bare wire; built-in speaker (mutually exclusive)) |
| Alarm Input | 2-ch, digital input (0–5 VDC) |
| Alarm Output | 1-ch |
| Alarm Linkage | Capture; preset; tour; pattern; recording; alarm digital input; send email |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Certification | |
| Certifications | CE: EN55032/EN55024/EN50130-4 |
| Port | |
| Audio Input | 1 channel (LINE IN, bare wire) |
| Audio Output | 1 channel (LINE OUT, bare wire) |
| Alarm Input | 2 (on-off value input: 0–5 VDC) |
| Alarm Output | 1 |
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital input; audio; warning light |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power | |
| Power Supply | 12 VDC, 3 A ± 10%; PoE+ (802.3at) |
| Power Consumption | Basic: 12 W Max. (Basic power consumption + illuminator+sound and light warning +PTZ operation + Heater ): 25 W (12 VDC) |
| Environment | |
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity | ≤ 95% |
| Protection | TVS 6000 V lightning proof;IP66; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 160.0 mm × 184.4 mm × 304.6 mm (6.30" × 7.26" × 11.99")(L × W × H) |
| Net Weight | 3.41 kg (7.52 lb) |
