About
Description
Part Number: DHIPPTZ40/5XLR-D
Brand: SPRO
Camera Resolution 4 Megapixels
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Active Deterrence Yes
Tripwire Yes
Intrusion Yes
Face detection Yes
Style PTZ
SMD 3.0 (Smart Motion Detection 3.0) Yes
ColourNight 2.0 Yes
Experience ultimate protection with SPRO's Active Deterrence PTZ camera. With red and blue flashing lights, a built-in speaker, and ColourNight technology, it's designed to stop crime in its tracks. And with advanced features like Missing and Abandoned Object Detection, Loitering and Crowd Gathering Detection, and a 5x zoom, you'll have full control and insight over your property. Keep your home or business safe and secure with SPRO 4MP IP PTZ with Active Deterrence 2.0, 5x Zoom.
| Specifications: | |
|---|---|
| Model Number | DHIPPTZ40/5XLR-D |
| Image Sensor | 1/2.8" CMOS |
| Pixels | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/1 ~ 1/30,000s |
| ROM | 128 MB |
| RAM | 512 MB |
| Min. Illumination | Colour: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
| Illumination Distance | 50 m (164.04 ft) (IR) 30 m (98.43 ft) (Warm light) |
| Illumination On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 2 (IR) 2 (Warm light) 1 (Red light) 1 (Blue light) |
| Lens | |
| Lens Type | 2.7 mm–13.5 mm |
| Max Aperture | F1.6–F3.0 |
| Field of View | H: 94.9°–30.1°; V: 51°–17.1°; D: 112.3°–34.6° |
| Optical Zoom | 5x |
| Focus Control | Auto / Semi-Auto / Manual |
| Close Focus Distance | 1.5 m (4.92 ft) |
| Iris Control | Fixed |
| DORI Distance |
Detect: 270 m (885.83 ft) Observe: 106.6 m (349.74 ft) Recognise: 54 m (117.17 ft) Identify: 27 m (88.58 ft) |
| PTZ | |
| Pan/Tilt/Rotation | Pan: 0° to 355° Tilt: –15° to +90° |
| Manual Control Speed | Pan: 0.1°/s–36°/s Tilt: 0.1°/s–25.8°/s |
| Preset Speed | Pan: 35.7°/s; Tilt: 27.1°/s |
| Preset | 300 |
| Power-off Memory | Yes |
| Idle Motion | Preset |
| Intelligence | |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
| Face Detection |
Supports face detection, snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first |
| SMD | Yes |
| Auto Tracking | Yes |
| Active Deterrence | |
| Light Warning | Red and blue light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low |
| Sound Warning | Offers 11 types of sound alarms, and supports importing up to 10 custom sound alarms. The sound alarm can be set to play 1 to 10 times |
| Video | |
| Video Compression | H.264H;H.264B;Smart H.265+; H.264;H.265;MJPEG(Sub Stream); Smart H.264+ |
| Streaming Capability | 3 Streams |
| Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p(1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) |
| Video Frame Rate | Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/CIF/VGA@ (1–25/30 fps) Sub stream 2: 720p @(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 96 kbps–14848 kbps H.265: 38 kbps–8960 kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Gain Control | Auto/ Manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest | Yes |
| Image Stabilisation | Electronic (EIS) |
| Defog | Electronic |
| Digital Zoom | 16x |
| Iage Rotation | 180° |
| S/N Ratiom | ≥ 55 dB |
| Audio | |
| Compression | G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM |
| Network | |
| Network Port | RJ-45 (10/100Base-T) |
| Network Protocol |
FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RT P;802.1x;HTTPS; SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;U DP;IGMP;SMB;HTTP;SSL;DHCP; SMTP;Qos;RTSP;ARP |
| Interoperability | CGI;SDK;ONVIF (Profile S&G&T);P2P |
| Streaming Method | Unicast / Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | FTP / SFTP; Micro SD card (512 GB); NAS |
| Browser |
IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
| Management Software | DMSS |
| Mobile Client | IOS; Android |
| Certification | |
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 |
| Port | |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)) |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input | 1/1 |
| Alarm Output | 1/1 |
| Alarm Linkage | Capture; recording; send email; preset; alarm digital input; audio; warning light |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power | |
| Power Supply | 12 VDC, 2 A ± 10% PoE+ (802.3at) |
| Power Consumption | Basic: 4.5 W Max.: 15 W (illuminator + PTZ + speaker + heating glass) |
| Environment | |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Protection | IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 142.6 mm × 140 mm × 236.1 mm (5.61" × 5.51" × 9.29") |
| Net Weight | 1.5 kg (3.31 lb) |
| Gross Weight | 2.1 kg (4.63 lb) |
Description
Part Number: DHIPPTZ40/5XLR-D
Brand: SPRO
Camera Resolution 4 Megapixels
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Active Deterrence Yes
Tripwire Yes
Intrusion Yes
Face detection Yes
Style PTZ
SMD 3.0 (Smart Motion Detection 3.0) Yes
ColourNight 2.0 Yes
Experience ultimate protection with SPRO's Active Deterrence PTZ camera. With red and blue flashing lights, a built-in speaker, and ColourNight technology, it's designed to stop crime in its tracks. And with advanced features like Missing and Abandoned Object Detection, Loitering and Crowd Gathering Detection, and a 5x zoom, you'll have full control and insight over your property. Keep your home or business safe and secure with SPRO 4MP IP PTZ with Active Deterrence 2.0, 5x Zoom.
| Specifications: | |
|---|---|
| Model Number | DHIPPTZ40/5XLR-D |
| Image Sensor | 1/2.8" CMOS |
| Pixels | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/1 ~ 1/30,000s |
| ROM | 128 MB |
| RAM | 512 MB |
| Min. Illumination | Colour: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
| Illumination Distance | 50 m (164.04 ft) (IR) 30 m (98.43 ft) (Warm light) |
| Illumination On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 2 (IR) 2 (Warm light) 1 (Red light) 1 (Blue light) |
| Lens | |
| Lens Type | 2.7 mm–13.5 mm |
| Max Aperture | F1.6–F3.0 |
| Field of View | H: 94.9°–30.1°; V: 51°–17.1°; D: 112.3°–34.6° |
| Optical Zoom | 5x |
| Focus Control | Auto / Semi-Auto / Manual |
| Close Focus Distance | 1.5 m (4.92 ft) |
| Iris Control | Fixed |
| DORI Distance |
Detect: 270 m (885.83 ft) Observe: 106.6 m (349.74 ft) Recognise: 54 m (117.17 ft) Identify: 27 m (88.58 ft) |
| PTZ | |
| Pan/Tilt/Rotation | Pan: 0° to 355° Tilt: –15° to +90° |
| Manual Control Speed | Pan: 0.1°/s–36°/s Tilt: 0.1°/s–25.8°/s |
| Preset Speed | Pan: 35.7°/s; Tilt: 27.1°/s |
| Preset | 300 |
| Power-off Memory | Yes |
| Idle Motion | Preset |
| Intelligence | |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
| Face Detection |
Supports face detection, snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first |
| SMD | Yes |
| Auto Tracking | Yes |
| Active Deterrence | |
| Light Warning | Red and blue light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low |
| Sound Warning | Offers 11 types of sound alarms, and supports importing up to 10 custom sound alarms. The sound alarm can be set to play 1 to 10 times |
| Video | |
| Video Compression | H.264H;H.264B;Smart H.265+; H.264;H.265;MJPEG(Sub Stream); Smart H.264+ |
| Streaming Capability | 3 Streams |
| Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p(1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) |
| Video Frame Rate | Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/CIF/VGA@ (1–25/30 fps) Sub stream 2: 720p @(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 96 kbps–14848 kbps H.265: 38 kbps–8960 kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Gain Control | Auto/ Manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest | Yes |
| Image Stabilisation | Electronic (EIS) |
| Defog | Electronic |
| Digital Zoom | 16x |
| Iage Rotation | 180° |
| S/N Ratiom | ≥ 55 dB |
| Audio | |
| Compression | G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM |
| Network | |
| Network Port | RJ-45 (10/100Base-T) |
| Network Protocol |
FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RT P;802.1x;HTTPS; SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;U DP;IGMP;SMB;HTTP;SSL;DHCP; SMTP;Qos;RTSP;ARP |
| Interoperability | CGI;SDK;ONVIF (Profile S&G&T);P2P |
| Streaming Method | Unicast / Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | FTP / SFTP; Micro SD card (512 GB); NAS |
| Browser |
IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
| Management Software | DMSS |
| Mobile Client | IOS; Android |
| Certification | |
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 |
| Port | |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)) |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input | 1/1 |
| Alarm Output | 1/1 |
| Alarm Linkage | Capture; recording; send email; preset; alarm digital input; audio; warning light |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power | |
| Power Supply | 12 VDC, 2 A ± 10% PoE+ (802.3at) |
| Power Consumption | Basic: 4.5 W Max.: 15 W (illuminator + PTZ + speaker + heating glass) |
| Environment | |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Protection | IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 142.6 mm × 140 mm × 236.1 mm (5.61" × 5.51" × 9.29") |
| Net Weight | 1.5 kg (3.31 lb) |
| Gross Weight | 2.1 kg (4.63 lb) |
SPRO
by
SPRO
SPRO 4MP IP PTZ with Active Deterrence 2.0, 5x Zoom
- Regular price
- £248.44
- Sale price
- £248.44
- Regular price
-
£279.99
Tax included.
