About
Description
Part Number: DHIPD40/28LRW-MS
Brand: SPRO
Camera Resolution 4 Megapixels
Lens Fixed Lens
Codec recording H.265
IR Distance Up to 30m IR distance
LED Distance Up to 30m LED distance
Built-in Mic. Yes
Speaker Built-in Yes
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Active Deterrence Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
WDR 120dB
Style Turret
ColourNight 2.0 Yes
Active Deterrence Lite Yes
The SPRO Active Deterrence LITE with ColourNight 2.0 cameras includes a built-in siren feature, adding an extra layer of security for your premises. Upon AI Human detection, the cameras not only illuminate the area with their powerful white light but also can emit a LOUD siren. This dual response effectively deters potential intruders and alerts users to any suspicious activity. The combination of full-colour night vision, AI-activated lighting, and an audible alarm makes the new SPRO Active Deterrence LITE cameras an unparalleled choice for night-time surveillance.
With the SPRO Active Deterrence LITE cameras, you have the power to choose the mode that best suits your security needs. Whether you prefer the energy-efficient AI-activated lighting or the continuous illumination for maximum visibility, the control is entirely in your hands. Customise your surveillance setup to ensure the optimal balance of security and efficiency.
The combination of ColourNight 2.0, high-resolution imaging, intelligent detection capabilities, and robust deterrent features makes the SPRO Active Deterrence LITE cameras an excellent choice for anyone seeking advanced night-time security solutions.
Key Features:
- H.265
- 4 Megapixel
- 2.8mm Fixed Lens
- Microphone built-in
- Speaker / Siren built-in
- Two-way-Audio
- Classication of Human & Vehicle
- Warm Light Range: Up to 30m
- IR range: Up to 30m
- Perimeter Protection
- SMD+
- 120dB WDR
- Metal Housing
- IP67 Waterproof
- DC12V/POE
| Specifications: | |
|---|---|
| Model Number | DHIPD40/28LRW-MS |
| Image Sensor | 1/2.9" CMOS |
| Effective Pixels | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.004 lux@F1.0 (Colour, 30 IRE)
0.0004 lux@F1.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
| S/N Ratio | ＞56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR); 30 m (98.43 ft) (Warm light) |
| Illuminator On/Off Control | Auto/ Manual |
| Illuminator Number | 1 (IR LED); 1 (Warm light) |
| Pan/Tilt/Rotation Range | Horizontal: 0°–360°, Vertical: 0°–78°, Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Max. Aperture | F1.0 |
| Field of View | H: 101.6°; V: 54.8°; D: 122.1° |
| Iris Type | Fixed |
| Close Focus Distance | 1.4 m (4.59 ft) |
| DORI Distance | Detect: 63.8 m Observe: 25.5 m Recognise: 12.8 m Identify: 6.4 m |
| Intelligence | |
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| SMD | SMD Plus |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+/ Smart H.264+ |
| Video Frame Rate |
Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps);
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps);
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
| Stream Capability | 2 Streams |
| Resolution |
4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2304 × 1296);
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720);
D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
| Bit Rate Control | CBR / VBR |
| Video Bit Rate |
H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps
|
| Day/Night | Auto(ICR) / Colour/ B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D NR |
| Motion Detection | Off / On (4 Areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Rotation | 0°/ 90°/ 180°/ 270° (Support 90°/270° with 2688×1520 resolution and lower.) |
| Mirror | Yes |
| Privacy Masking | 4 Areas |
| Audio | |
| Built-in MIC | Yes |
| Built-in Speaker | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm | |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP
conflict; illegal access; motion detection; video tampering; tripwire;
intrusion; audio detection; voltage detection; SMD; security exception
|
| Network | |
| Network | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP;
SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; NFS; P2P;
auto registration
|
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; |
| User/Host | 6 (Total bandwidth: 36 M) |
| Storage | FTP; SFTP; Micro SD Card (support max. 256 G); Cloud; NAS |
| Browser | IE, Chrome, Firefox |
| Management Software | DMSS |
| Mobile Phone | iOS & Android |
| Cyber Security |
Configuration encryption;Trusted execution;Digest;Security logs;
WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC
filtering;HTTPS;Trusted upgrade;Trusted boot;Generation and
importing of X.509 certification
|
| Certification | |
| Certifications |
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
|
| General | |
| Power Supply | 12V DC/PoE |
| Power Consumption |
Basic: 2 W (12 VDC), 2.6 W (PoE)
Max. (H.265 + intelligence on + WDR + IR intensity + warm light
deterrence + speaker): 8.6 W (12 VDC), 10.1 W (PoE)
|
| Operating Conditions | -40ºC ~ +60ºC (-40ºF ~ +140ºF)/ ≤95% RH |
| Storage Conditions | -40ºC ~ +60ºC (-40ºF ~ +140ºF)/ ≤95% RH |
| Ingress Protection | IP67 |
| Casing | Inner core: Metal - Cover: Plastic |
| Dimensions | 89.2 mm × Φ105 mm |
| Net Weight | 0.39 kg (0.86 lb) |
| Gross Weight | 0.57 kg (1.26 lb) |
