About
Description
Part Number: DHIPD80/28LRG/30-D-V3
Brand: SPRO
Camera Resolution 8 Megapixels
Lens Fixed Lens
Codec recording H.265
IR Distance Up to 30m IR distance
LED Distance Up to 30m LED distance
Built-in Mic. Yes
Speaker Built-in Yes
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Audio over CAT5e Yes
Active Deterrence Yes
Colour Night Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
WDR 120dB
Style Turret
Introducing the SPRO Smart Dual Illumination Active Deterrence camera series, meticulously crafted to proactively deter crime. These cutting-edge cameras boast red and blue flashing lights, a two-way audio system with a built-in speaker, and pre-recorded messages to enhance security measures.
Equipped with Color Night 2.0 technology, our cameras redefine nighttime surveillance by capturing vivid, full-color images in low-light conditions. The innovative inclusion of white light LEDs ensures optimal scene illumination.
Key Features:
-
8 megapixel
-
H.265
-
2.8mm Lens
-
Up to 30m LED distance (smart LED)
-
Up to 30m IR distance (smart LED)
-
SMD 4.0 (Smart motion detection)
-
Intrusion (human & vehicle classification)
-
Tripwire (human & vehicle classification)
-
Two-way-audio
-
Microphone built-in (audio over CAT5e cable)
-
120dB WDR
-
IP67 waterproof
- DC 12V/POE
| Specifications: | |
|---|---|
| Model Number | DHIPD80/28LRG/30-D-V3 |
| Image Sensor | 1/2.8” 8Megapixel progressive CMOS |
| Effective Pixels | 3840 (H) × 2160 (V), 8MP |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.004 lux@F1.0 (Colour, 30 IRE) 0.0004 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on) |
| S/N Ratio | ＞56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR) 30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control | Auto/ Manual |
| Illuminator Number | 1 (IR LED) 1 (warm light) |
| Pan/ Tilt/ Rotation Range | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Field of View | Horizontal: 106°; vertical: 55°; diagonal: 125° |
| Iris Type | Fixed |
| Close Focus Distance | 2.0 m (6.56 ft) |
| DORI Distance | Detect: 91 m Observe: 36.4 m Recognize: 18.2 m Identify: 9.1 m |
| Professional, intelligent | |
| IVS (Perimeter Protection) | Tripwire; intrusion (Recognition of human and vehicle) |
| SMD 4.0 | Less false alarm, longer detection distance. |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+/ Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 3840 × 2160@(1 fps–30 fps) Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps) Third stream: 1920 × 1080 @1-25/30 fps *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability | 3 Streams |
| Resolution | 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 3 Kbps–20480 Kbps H.265: 3 Kbps–20480 Kbps |
| Day/Night | Auto (ICR)/Colour/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation | Yes |
| White Balance | Auto/ Natural/ Street Lamp/ Outdoor /Manual / regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Areas) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/ 90°/ 180°/ 270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 Areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception. |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade. |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| Max. User Access | 20 (Total bandwidth: 72 M) |
| Storage | Micro SD card (Support max. 256 G) / Local PC for instant recording |
| Web Viewer | IE, Chrome, Firefox |
| Management Software | SPRO CSS |
| Smart Phone | iPhone, iPad & Android |
| Port | |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC |
| Alarm Output | 1 channel out: 300mA 12V DC |
| General | |
| Power Supply | DC12V, POE |
| Power Consumption | Basic: 5.2 W (12 VDC); 5.5 W (PoE) Max. (H.265+main stream/IR intensity+warm light on): 9.2 W (12 VDC) 10.2 W (PoE) |
| Operating Conditions | -40ºC ~ +60ºC / Less than 95% RH |
| Storage Conditions | -40ºC ~ +60ºC |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | φ122.0mm × 110.9mm |
| Net Weight | 754g |
| Gross Weight | 915g |
Description
Part Number: DHIPD80/28LRG/30-D-V3
Brand: SPRO
Camera Resolution 8 Megapixels
Lens Fixed Lens
Codec recording H.265
IR Distance Up to 30m IR distance
LED Distance Up to 30m LED distance
Built-in Mic. Yes
Speaker Built-in Yes
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Audio over CAT5e Yes
Active Deterrence Yes
Colour Night Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
WDR 120dB
Style Turret
Introducing the SPRO Smart Dual Illumination Active Deterrence camera series, meticulously crafted to proactively deter crime. These cutting-edge cameras boast red and blue flashing lights, a two-way audio system with a built-in speaker, and pre-recorded messages to enhance security measures.
Equipped with Color Night 2.0 technology, our cameras redefine nighttime surveillance by capturing vivid, full-color images in low-light conditions. The innovative inclusion of white light LEDs ensures optimal scene illumination.
Key Features:
-
8 megapixel
-
H.265
-
2.8mm Lens
-
Up to 30m LED distance (smart LED)
-
Up to 30m IR distance (smart LED)
-
SMD 4.0 (Smart motion detection)
-
Intrusion (human & vehicle classification)
-
Tripwire (human & vehicle classification)
-
Two-way-audio
-
Microphone built-in (audio over CAT5e cable)
-
120dB WDR
-
IP67 waterproof
- DC 12V/POE
| Specifications: | |
|---|---|
| Model Number | DHIPD80/28LRG/30-D-V3 |
| Image Sensor | 1/2.8” 8Megapixel progressive CMOS |
| Effective Pixels | 3840 (H) × 2160 (V), 8MP |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.004 lux@F1.0 (Colour, 30 IRE) 0.0004 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on) |
| S/N Ratio | ＞56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR) 30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control | Auto/ Manual |
| Illuminator Number | 1 (IR LED) 1 (warm light) |
| Pan/ Tilt/ Rotation Range | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Field of View | Horizontal: 106°; vertical: 55°; diagonal: 125° |
| Iris Type | Fixed |
| Close Focus Distance | 2.0 m (6.56 ft) |
| DORI Distance | Detect: 91 m Observe: 36.4 m Recognize: 18.2 m Identify: 9.1 m |
| Professional, intelligent | |
| IVS (Perimeter Protection) | Tripwire; intrusion (Recognition of human and vehicle) |
| SMD 4.0 | Less false alarm, longer detection distance. |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+/ Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 3840 × 2160@(1 fps–30 fps) Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps) Third stream: 1920 × 1080 @1-25/30 fps *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability | 3 Streams |
| Resolution | 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 3 Kbps–20480 Kbps H.265: 3 Kbps–20480 Kbps |
| Day/Night | Auto (ICR)/Colour/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation | Yes |
| White Balance | Auto/ Natural/ Street Lamp/ Outdoor /Manual / regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Areas) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/ 90°/ 180°/ 270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 Areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception. |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade. |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| Max. User Access | 20 (Total bandwidth: 72 M) |
| Storage | Micro SD card (Support max. 256 G) / Local PC for instant recording |
| Web Viewer | IE, Chrome, Firefox |
| Management Software | SPRO CSS |
| Smart Phone | iPhone, iPad & Android |
| Port | |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC |
| Alarm Output | 1 channel out: 300mA 12V DC |
| General | |
| Power Supply | DC12V, POE |
| Power Consumption | Basic: 5.2 W (12 VDC); 5.5 W (PoE) Max. (H.265+main stream/IR intensity+warm light on): 9.2 W (12 VDC) 10.2 W (PoE) |
| Operating Conditions | -40ºC ~ +60ºC / Less than 95% RH |
| Storage Conditions | -40ºC ~ +60ºC |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | φ122.0mm × 110.9mm |
| Net Weight | 754g |
| Gross Weight | 915g |
