About
Description
Part Number: DHDVR32-B6-0TB
Brand: SPRO
Recorder Resolution 8MP
Audio over co-ax On each channel
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
Face detection Yes
Face Recognition Yes
BNC Channels 32 Channel
Smart Dual Illumination Supported Yes
The SPRO B6 8MP 32 Channels 5in1 with AI offers unparalleled precision in its crystal-clear images and videos, whether monitoring a large area or zooming in on specific points of interest. Additionally, its 32 channels provide exceptional coverage for enhanced clarity and detail.
Equip your commercial space with comprehensive surveillance using SPRO B6 8MP 32 Channels 5in1 with AI. With up to 32 channels available, you can easily monitor multiple areas without any blind spots. Expand your security system as needed by connecting up to 32 cameras.
What sets the SPRO B6 apart is its AI capabilities. Powered by advanced algorithms, it can detect and analyse human and vehicle movement, reducing false alarms caused by irrelevant events. This intelligent feature not only saves time and resources but also enhances the overall effectiveness of your surveillance system. Increase the precision of your surveillance system with AI-powered detection and analysis of human and vehicle movement. Our advanced algorithms minimize false alarms caused by irrelevant events, saving you valuable time and resources while maximizing effectiveness.
Key Features
- H.265+ / H.265 dual-stream video compression.
- Supports 32-channel AI-Coding.
- Supports HDCVI/AHD/TVI/CVBS/IP video inputs.
- Max 32 channels IP camera inputs, each channel up to 8MP; Max 128 Mbps incoming bandwidth.
- Up to 12 channels video stream (analogue channel) perimeter protection.
- Up to 32 channels video stream (analogue channel) SMD plus.
- Up to 6 channels video stream (analogue channel) human face recognition.
- IoT & POS functionalities
| Specifications: | |
|---|---|
| Model Number | DHDVR32-B6 |
| Main Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| Operating Interface | Web; Local GUI |
| Perimeter Protection | |
| Performance | Advanced Model: 6 channels, 10 IVS for each channel General Model: 12 channels, 10 IVS for each channel |
| Face Detection | |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance AI by Recorder |
6 channel (up to 12 face image/s each channel) |
| Face Recognition | |
| Face Database Capacity | Up to 10 face databases with 20 000 face images in total. Name, gender, birthday, address, certificate type, certificate No., countries & regions and state can be added to each face image. |
| Face Recognition Performance AI by Recorder |
6 channels |
| SMD Plus | |
| SMD Plus by Recorder | 32 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| Audio and Video | |
| Analogue Camera Input | 32 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect |
| Camera Input | 1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps. 2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. 3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. |
| IP Camera Input | Up to 32 channels of IPC access 32 channels (analogue channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps |
| Encoding Capacity | Main stream: 4K@(1fps-7fps); 6 MP@(1fps-10fps); 5 MP@(1fps-12fps); 4K-N, 4 MP, 3 MP@(1fps-15fps); 4M-N, 1080p, 720p, 960H, D1,CIF@ (1fps–25/30fps); Sub stream: 960H@(1fps–15fps); D1/CIF@ (1 fps–25/30fps) |
| Dual-stream | Yes |
| Video Bit Rate | 32kbps-6144kbps |
| Audio Sampling | 8kHz, 16 bit |
| Audio Bit Rate | 64kbps |
| Video Output | 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. |
| Multi-screen Display | 1/4/8/9/16/25/36 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Samsung |
| Compression Standard | |
| Video Compression | AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression | G.711a; G.711u; PCM |
| Network | |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 21.12; CGI |
| Browser | Chrome, IE9 or later, Firefox |
| Network Mode | Single-address mode |
| Recording Playback | |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Record Playback | 1/4/9/16 |
| Backup Method | USB device and network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Storage | |
| Disk Group | Yes |
| Alarm | |
| General Alarm | Motion detection; video loss; tampering; local alarm |
| Anomaly Alarm | No disk; storage error; disk full; camera offline; IP conflict; MAC conflict |
| Intelligent Alarm | Face Detection; face recognition; perimeter protection |
| Alarm Linkage | Record; snapshot (panoramic); IPC external alarm output; access controller; voice prompt; buzzer; log; preset; email |
| Ports | |
| TV Output | 1 channel |
| Audio Input | 1-channel RCA 32-channel BNC (Coaxial Audio) |
| Audio Output | 1-channel RCA |
| Two-way Talk | Yes (share the same audio input with the first channel) |
| HDD Interface | 2 SATA ports, up to 16TB capacity for each disk. The Maximum HDD capacity varies with environment temperature. |
| RS-485 | 1 port, for PTZ control |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port |
| HDMI | 1 |
| VGA | 1 |
| Network Port | 1(10/100/1000 Mbps Ethernet port, RJ-45 ) |
| General | |
| Power Supply | DV12V, 5A |
| Power Consumption | <32W (without HDD) |
| Net Weight | 2.50kg (5.52lb) |
| Gross Weight | 4.10kg (9.04lb) |
| Product Dimensions | 375.0 mm × 334.4 mm × 53.0 mm (14.76''×13.17''×2.09'') (W×D× H) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Operating Humidity | 10%–90% (RH) |
| Installation | Rack or Desktop |
| Certification | |
| Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B |
